aDA-M4-2P300 -
Power amplifier module for aDA-M4 chassis, Dual channel
Specification:
Specification:
| Model | aDA-M4-2P300 | ||
| Power | 8 Ohms: 2x300 W, 4 Ohms: 2x450 W | ||
| Frequency range | 20 Hz-20 kHz | ||
| Harmonic distortion | ≤0,01% | ||
| Signal-to-noise ratio | ≥101 dB | ||
| Sensitivity | 0.775 V-1V-1.5 V | ||
| Input impedance | balance 20 kΩ / unbalance 10 kΩ | ||
| Dump factor | ≥600 | ||
| Channel Section | ≥70 dB | ||
| Food | AC 220V / 50-60Hz | ||
| Dimensions (HxWxD) | 480x355x45 mm |
